Description
Features :
◆ 3 times peak power, excellent loading capability.
◆ Combine inverter/solar controller/battery all in one.
◆ Multiple output: 2*AC output socket, 4*DC 12V, 2*USB.
◆ Working mode AC prior/ECO mode/Solar prior selectable.
◆ AC charging current 0-10A selectable.
◆ LVD/HVD/Charging voltage adjutable, suitable for kinds of battery
◆ Adding fault code to monitor real-time work situations.
◆ Continuous stable pure sine wave output with inbuilt AVR stabilizer.
◆ Digital LCD and LED for visualization of operation status of the equipment.
◆ Inbuilt automatic AC charger and AC mains switcher, stwitch time ≤ 4ms.
Parameters Table:
| Model : ZD-ESS | 102P/W | |
| Capacity | Rated power | 1000W |
| Peak power（20ms） | 3000VA | |
| Input | Stardard battery voltage | 24VDC |
| AC input voltage range | 73~138VAC(110VAC) / 83~148VAC(120VAC) /145~275VAC(220VAC)/155~285VAC(230VAC)/165~295VAC(240VAC) | |
| AC input frequency range | 45Hz~55Hz（50Hz);55Hz~65Hz（60Hz) | |
| Output | Conversion efficiency | ≥85%(Battery mode); >99%(AC mode) |
| AC Output voltage | 110VAC±2% / 120VAC±2% / 220VAC±2% / 230VAC±2%/ 240VAC±2%(Battery mode); 110VAC±10% / 120VAC±10% / 220VAC±10% / 230VAC±10% / 240VAC±10%(AC mode) |
|
| AC Output frequency | 50/60Hz±1%(Battery mode); Tracking Automatically(AC mode) | |
| AC Output waveform | Pure Sine Wave | |
| THD | ≤3%（Linear load) | |
| DC Output voltage | 4*DC 12V; 2*USB（5V） | |
| AC charger | AC charging current | 0~10A(Depends on model) |
| AC charging method | Three-stage(constant current, constant voltage, floating charge) | |
| solar charger （Optional） | Charging mode | PWM/MPPT |
| Max PV input voltage(Voc) (At the lowest temperature) |
PWM: 50V; MPPT: 150V | |
| PV input voltage range | PWM: 30~44V; MPPT: 30~120V | |
| Charge & discharge current | 40A | |
| Max PV input power | 1120W | |
| Inbuilt battery | Capacity | 2*100AH |
| Battery size(LxWxH)/pcs | 407*174*210（240) | |
| Other | Transfer time | ≤4ms |
| Protection | with over-voltage, low-voltage, overload, short circuit, high tempreature protections | |
| Display | LCD & LED | |
| Cooling way | Cooling fan in intelligent control | |
| Working mode (selectable) |
d1 | AC priority mode |
| d2 | ECO mode | |
| d3 | Solar priority mode | |
| Work environment |
Operating temperature | -10℃~40℃ |
| Storage temperature | -15℃~60℃ | |
| Elevation | 2000m（More than derating） | |
| Humidity | 0%~95% ,No condensation | |
| Physical | Dimention L x W x H(mm) | 465*210*775 |
| Net weight(kg)(without battery) | 21 | |
| Packing | Dimention L x W x H(mm) | 535*270*890 |
| Gross weight(kg)(without battery) | 26 | |
| Quantity/CTN | 1pcs per wooden case | |
